Solid Mag welding wire for welding Duplex stainless steels.

APPLICATIONS

Used for pipe work and general fabrication in the offshore oil and gas and chemical process industries. Also suitable for cladding steels to obtain corrosion resistant layers.

PROPERTIES

A continuous, solid, corrosion-resistant, duplex wire for welding austenitic-ferritic stainless alloys of the 22% Cr, 5% Ni, 3% Mo types. 2209 has high general corrosion resistance. In media containing chloride and hydrogen sulphide, the alloy has a high resistance to intergranular corrosion, pitting and especially to stress corrosion. The alloy is used in a variety of applications across all industrial segments.

CLASSIFICATION

AWS

A 5.9: ER 2209

EN ISO

14343-A: G 22 9 3 N L

DIN: W.Nr.

1.4462

DIN

8556: SG X2CrNiMo 22 9 3

SUITABLE FOR

Welding wrought, forged or cast duplex stainless steels in the as welded condition. Also suitable for dissimilar welding of low alloyed steels and common stainless steels, UNS S31803, S32205, UR 45N & UR 45N+, 2101, 2205, SAF 2205 Fafer 4462, NKCr22, SM22Cr, Falc 223 UNS S32304 : UR 35 N SAF 2304
W.Nr: 1.4162, 1.4462, X2CrNiMoN 22 5 3, 1.4362, X2CrNiN 23 4, 1.4463, 1.4460, 1.4583

APPROVALS

TUV (12397.00), CE approved.

WELDING POSITIONS:

TYPICAL ALL WELD ANALYSIS

C	Mn	Si	Cr	Ni	Mo	N
0,025	1,60	0,5	23.0	9.0	3.0	0,14

MECHANICAL PROPERTIES

Heat treatment	RP0,2	Rm	A5	Impact energy (J) ISO-V			Hardness
	(N/mm2)	(N/mm2)	(%)	+20C	-40°C	-60C	HRc / HV
AW	>560	>730	26	>80		>37

AW: as welded

REDRYING TEMPERATURE

not required

WELDING PARAMETERS / PACKING

Welding Parameters			Packing
D (mm)	Voltage (V)	Current (A) DC+	spool type	spool weight (kg)	pallet weight (kg)
0,8	16-22	50-140	D-200 / K-300 / POP	5 / 15 / 250	1200 / 1080 / 1000
1,0	16-24	80-190	D-200 / K-300 / POP	5 / 15 / 250	1200 / 1080 / 1000
1,2	20-28	180-280	D-200 / K-300 / POP	5 / 15 / 250	1200 / 1080 / 1000

GAS ACC. EN ISO 14175:

M12, M13

2209 Duplex
