DRATEC

DT-NiFe






DT-NiFe Nickel Alloy MIG/MAG-Wire
TIG – Rods




Specifications DIN EN ISO 1071 S C NiFe-1
BS: 2901 NA-47

Application NiFe-wire/rod for welding cast irons
(ductile, malleable and grey cast irons)





Chemical Composition C: 0,05  Cu : 0,35 Mn: 0.60  Fe: 44-46,0  Ni: mind. 53,0
Element by weight (%)





Mechanical Properties 0,2%Elongation (Rp0,2) 300 N/mm²
(typical) Tensile Strength (Rm) 450 N/mm²
Elongation (A)(Lo=5do) 10%



Approvals MIG: DB




Shielding gas/Polarity WIG: (ISO 14175) I1 (=-)

MSG:  (ISO 14175) I1, M12 (=+)




Typical Base Material spheroidal graphite cast iron (GJS)
EN-GJS-350-22-LT bis EN-GJS700-2 (GGG35 bis GGG70)
GJS with X120Mn12 (1.3401)
Steel (1.2) with X120Mn12 (1.3401)




Packaging MIG/MAG:  spools D 100 / D 200 / K 200 / K 300
TIG: 10-kg-boxes
