Arc Welding Service

CATEGORY

TYPE

The first Basic under water welding electrode with extreme low carbon content.

APPLICATIONS

Welding standard ship steel grades A, B & D in submerged conditions in case standard well known underwater electrodes fail to offer proper ductility and crack resistance exceeding the requirements for AWS D3.6M-99.

PROPERTIES

AquaForce LC is the first Basic electrode that was developed with "Hydrophobic sand" to offer maximum moisture resistance. AquaForce LC is currently the only available electrode that is able to produce flat (not concave) welds with deeper penetration in all positions including PB, PC, PD, PE and PG position. The special (Armcore) ultra low carbon core wire of this electrode reduces the hardness from 195 HV to 165 HV hardness in the pure weldmetal caused by the high cooling rate (T8-5) when welding under water. AquaForce LC`s unique Basic coating reduces Oxygen content in the weldmetal to obtain better ductility than can be achieved with standard wet welding rutile electrodes.

CLASSIFICATION

AWS

A 5.1: ~E 6018

EN ISO

2560-A: E 38 2 B 14

SUITABLE FOR

DIN:
Unalloyed steels:
Boiler plates:
Pipe steels:
-
Shipbilding plates:
Steel castings:
Thin sheets:

-
St 33 to St 52.3
HI, HII, 17 Mn4
St 35 to St 52.4
StE 210.7 to StE 360.7
A, B, D
GS-38 to GS-52
1623/1

W.Nr.:
1.0035 to 1.0570
1.0345, 1.0425, 1.0481
1.0308 to 1.0581
1.0307 to 1.0582
1.0440, 1.0472, 1.0475
1.0416 to 1.0551

APPROVALS

CE approved

WELDING POSITIONS:

ALL WELD METAL ANALYSIS % (NOMINAL)

C	Mn	Si	P	S
<0.05	0,45	0,20	<0.025	<0.025

MECHANICAL PROPERTIES (ALL WELD METAL)

Heat	R_P0,2	Rm	A5	Impact Energy (J) ISO-V			Hardness
Treatment	(N/mm²)	(N/mm²)	(%)	0°C	-20°C	-40°C	HV (all weld)
AW	>460	480-590		>32	>27		169

AW: as welded

REDRYING TEMPERATURE

not required

WELDING PARAMETERS / PACKING

Welding Parameters			Packing
D (mm)	Length (mm)	Current (A) (DC+)	kg / can	pcs / pack	kg / 6 pack
3.2	350	140-180	2.8	80	16.8
4.0	350	150-210	2.8	55	16.8
